Hitch
    1,110
    UVW
    8,800
    GVWR
    9,995
    Length
    35' 10"
    Height
    11' 11"
    Sleeps
    N/A
    MSRP
    $56,799
    DOWNLOAD SPEC SHEET
    OVERALL SIZE
    Exterior Height11' 11"
    Exterior Height (w/opt. AC)
      Exterior Length35' 10"
      Exterior Width8'
      Exterior Width (w/ slide out)11' 1"
      Interior HeightN/A

      WEIGHTS
      Hitch / Pin Weight1,110
      UVW8,800
      GVWR9,995

      CAPACITY
      Fresh Water Capacity54
      Gray Water Capacity71
      Waste Water Capacity39
      Propane Tanks2
      LPG60
      Sleeping CapacityN/A
      APPLIANCES
      Water HeaterTankless
      Refrigerator16 cu. ft.
      Furnace35,000 BTU
      AC15,000 BTU

      RUNNING GEAR
      Axles2
      Wheel Size15 in.
      Tire SizeST225/75R15 LRE

      CONSTRUCTION
      Construction TypeAluminum Cage
      Floor R-ValueR-30
      Wall R-ValueR-9
      Roof R-ValueR-40
      Slide Room R-ValueR-9
      DIMENSIONS
      Standard Bed60 X 80 Queen Bed (King Opt.)
      Standard BunkN/A
      Shower30 x 48"

      EXTERIOR
      Slides2
      Awnings1
      Awning Length20'
      EXTERIOR
      • 80% Tint Radius Safety Glass Windows
      • Battery Kill Switch in Pass Thru Storage Area
      • 30# LP Bottles (2) with cover
      • 30" Radius Entry Door
      • Outside Shower
      • Factory Installed Roof Ladder
      • Marine Grade LED Hitch Light

      CONSTRUCTION
      • Gel Coat Exterior Sidewalls
      • Walk On Roof Decking
      • Residential 5" Truss Rafters (16" O.C.)
      • Fiberglass and Radiant Foil Roof and Front Cap Insulation
      • One-Piece TPO Roof Membrane with Limited Lifetime Warranty
      • Easy Access Low Point Drain Valves
      • Laminated Aluminum Framed Side Walls (R-9)
      • Laminated Aluminum Framed Roof and End Walls in Slide Rooms (R-9)
      • Aluminum Framed Main Floor (R-30*)
      • Residential Wood Framed Roof (R-40*)
      • Laminated Aluminum Framed Rear Wall (R-9)
      • Aerodynamic Front Cap w/ Max Turn Radius and Integrated LED Lights
      • Heated & Enclosed Dump Valves
      • Heated & Enclosed Underbelly w/ Circulating Heat
      • Thermofoil Insulation Under Holding Tanks
      • EZ Winterization Valve in Utility Center
      • Insulated Slideout Floors

      RUNNING GEAR
      • Aluminum Wheels with Goodyear Endurance Tires
      INTERIOR
      • Residential Hardwood Cabinet Doors
      • Solid Hardwood Drawer Fronts
      • Solid Core Cabinet Stiles
      • Pre-drilled and Screwed Cabinetry
      • Ball Bearing Full Extension Drawer Glides
      • Large Panoramic Slide Room Windows
      • Premium Congoleum Flooring
      • Ductless Flooring Throughout Living Area
      • Residential Style Window Treatment
      • LED Lighting with Motion Sensors (Key Areas)
      • Residential Matte Black Cabinet Hardware
      • Hardwood Galley Slide Trim Moldings
      • Adjustable A/C Vents
      • Tri-Fold Hide-A-Bed Sofa (Model Specific)
      • Blackout Roller Shade

      KITCHEN
      • Deep Seated Stainless Steel Sink
      • Modern Glass Refrigerator Door Fronts

      ELECTRICAL
      • Integrated Front Cap LED Lights
      • 180W Roof Mounted Solar Panel
      • Roof Mounted Quick Connect Plugs
      • 60 Amp Charge Controller
      • Solar Disconnect

      HVAC
      • Heat Duct and A/C Vents in Bathroom
      • 35K BTU High Capacity Furnace
      PLUMBING
      • High-Capacity Water Pump with Interior and Exterior Switch
      • Extra Large 2" Fresh Water Drain Valve

      BEDROOM
      • Functional Wardrobe Closet
      • 60 x 80 Mattress with Residential Bedspread
      • Oversized Bed Base Storage
      • Bedroom Heat Registers

      BATHROOM
      • Spacious Shower with Glass Door
      • Power Vent Fan
      • Large Vanity Top w/ Deep Sink
      • Large Medicine Cabinet with Mirror

      APPLIANCE
      • 12V 10 or 16 Cu.Ft. Refrigerator (Floorplan Specific)

      ELECTRONICS
      • Cable/SAT Prep
      • TravlFi On-Board WiFi Ready
      Peace of Mind Package
      • Residential Cabinetry
      • Universal All-In-One Docking Station
      • Metal Slam Latch Front Cargo Doors
      • On Demand Tankless Water Heater
      • Porcelain Toilet with Foot Flush
      • High-Rise Faucet with Pullout Sprayer
      • Aluminum Entry Steps
      • Theater Seats
      • Painted Fiberglass Front Cap
      • Residential Booth Dinette
      • LP Quick Connect
      • Anti-Lock Breaking System
      • Roller Shades
      • 6' Coiled Break Away Cable
      • Deep Seated Stainless Steel Kitchen Sink
      • Walk-on Roof
      • Aluminum Rims
      • Spare Tire & Carrier
      • 2” Receiver Hitch Upgrade
      • Solid Surface Countertops
      • Solid Surface Sink Covers
      Ultimate Power Package
      • 30" Stainless Steel Microwave
      • 15K Ducted Main A/C
      • "One-Touch" Electric LED Awning
      • Maxx Air Fan
      • AM/FM//HDMI/Bluetooth Stereo
      • 50 AMP Service, Wired and Framed for 2nd A/C
      • High Definition LED TV
      • Detachable Power Cord with LED Light
      • Power Front & Rear Stabilizer Jacks
      • LED Interior Lighting
      • Motion Sensor Entry Lighting (LED)
      • Compass Connect
      • Tire Linc TPMS
      Arctic 4-Seasons Protection Package
      • 35K BTU High Capacity Furnace
      • Double Insulated Roof and Front Cap
      • Heated and Enclosed Dump Valves
      • Heated and Enclosed Underbelly w/ Circulating Heat
      • Thermofoil Insulation under Holding Tanks
      • EZ Winterization Valve in Utility Center
      • Insulated Slide-out Floors
      • Dual Attic Vents
      • 12v Heat Pads on Holding Tanks
      Solar Package
      • 180W Roof Mounted Solar Panel
      • Roof Mounted Quick Connect Plugs
      • 60 Amp Charge Controller
      • 12V 10 Cu. Ft. Refrigerator
      • Inverter Prep
      • Solar Disconnect
