This travel trailer floorplan features a rear bathroom and mid kitchen with front Queen Bed.

This modest rear bath travel trailer packs a punch. Between its massive storage and removable table, everyone can relax and have fun without missing a single thing.

Hitch
497
UVW
5,125
GVWR
6,995
Length
25' 11"
Height
10' 10"
Sleeps
4
MSRP
$42,359
DOWNLOAD SPEC SHEET

OVERALL SIZE
Exterior Height 10' 10"
Exterior Height (w/opt. AC)    10' 10"
Exterior Length 25' 11"
Exterior Width 8'
Exterior Width (w/ slide out) 10'
Interior Height 78"

WEIGHTS
Hitch / Pin Weight 497
UVW 5,125
GVWR 6,995

CAPACITY
Fresh Water Capacity 43
Grey Water Capacity 82
Waste Water Capacity 37
Propane Tanks 2
LPG 40
Sleeping Capacity 4
APPLIANCES
Water Heater Tankless
Refrigerator 10 cu. ft.
Furnace 25,000 BTU
AC 15,000 BTU

RUNNING GEAR
Axles 2
Wheel Size 14 in.
Tire Size ST205/75R14LRD

CONSTRUCTION
Construction Type Aluminum Cage
Floor R-Value R-30
Wall R-Value R-7
Roof R-Value R-40
Slide Room R-Value R-7
DIMENSIONS
Standard Bed 60 X 80 Queen Bed
Standard Bunk N/A
Shower 27 X 36

EXTERIOR
Slides 1
Awnings 1
Awning Length 18
EXTERIOR
  • 80% Tint Radius Safety Glass Windows
  • 20# LP Bottles (2)
  • 28" Radius Entry Door
  • Extra Large 2” Fresh Water Drain Valve
  • Adjustable Power Awning w/ LED Lights
  • Power Tongue Jack
  • Aluminum Entry Steps
  • 6' Coiled Break Away Cable
  • Front Rock Guard

CONSTRUCTION
  • Gel Coated Fiberglass Exterior
  • One-Piece Roof Membrane with 18-Year Warranty
  • Easy Access Low Point Drain Valves
  • Friction Hinge Entry Door
  • Magnetic Storage Door Catches
  • Laminated Aluminum Framed Rear Wall (R-7)
  • Laminated Aluminum Framed Side Walls (R-7)
  • Laminated Aluminum Framed Roof and End Walls in Slide Rooms (R-7)
  • Laminated Aluminum Framed Main Floor (R-30)
  • 5" Radius Wood Framed Roof (R-40)
  • Heated & Enclosed Underbelly w/ Suspended Tanks
  • Double Insulated Roof & Front Wall
  • Heated & Enclosed Dump Valves
  • High Density Roof Insulation w/ Attic Vent
  • Moisture Barrier Floor Enclosure

RUNNING GEAR
  • Tire Linc TPMS Prep
  • Aluminum Rims
  • Spare Tire & Cover

FRAME & CHASSIS
  • Power Tongue Jack
INTERIOR
  • Solid Drawer Fronts
  • Glass Cabinet Door Inserts (Select Overhead Cabinets)
  • Solid Core Cabinet Stiles
  • Pre-Drilled and Screwed Face Frames
  • Ball Bearing Full Extension Drawer Glides
  • Large Panoramic Window
  • Telescoping Dinette Table
  • LED Interior Lighting

KITCHEN
  • Sink Cover
  • Residential Countertops
  • Deep Seated Stainless Steel Sink
  • Residential Pulldown Sprayer Faucet

ELECTRICAL
  • Battery Kill Switch (Pass Thru)
  • Monitor Panel w/ One Touch Compass Connect
  • 165W Roof Mounted Solar Panel
  • Roof Mounted Quick Connect Plugs
  • 25 Amp Charge Controller
  • 30 Amp Service
  • Detachable Power Cord
  • Motion Sensor LED Entry Lighting

HVAC
  • High Capacity Furnace
  • Designated Heat to Subfloor
  • Residential (Ductless) Heating System Throughout
  • Ducted Main A/C
PLUMBING
  • High-Capacity Water Pump
  • Oversized Tank Capacities

BEDROOM
  • Queen Murphy Bed w/ Storage Drawers (17MKE, 21BHE, & 25BHE)
  • Residential Bedspread
  • Master Suite with Queen Bed (22MLE, 22RBE, 23BHE, 23LDE)
  • Built-in Wardrobe Cubby Storage w/USB-C Charging Station and 110V Outlet

BATHROOM
  • Residential Walk-In Shower
  • Skylight Over Shower
  • Power Vent Fan
  • Medicine Cabinet with Mirror

APPLIANCE
  • Microwave
  • 3-Burner Range with Oven
  • 12V 10 CU FT Refrigerator

ELECTRONICS
  • Backup Camera Prep
  • Exterior Speakers
  • TV and Cable Prep
  • AM/FM Bluetooth Stereo
  • High Definition LED TV
  • Exterior Cable Hookup
Peace of Mind Package
  • Aluminum Entry Steps
  • Universal Docking Station
  • ON DEMAND Tankless Water Heater
  • Black Tank Flush
  • Spare Tire and Carrier
  • Nitrogen Filled Radial Tires
  • Front Rock Guard
  • Aluminum Rims
  • Premium Window Treatments
  • Residential Cabinetry
  • 6" Break Away Cable
  • Dedicated Sewer Hose Carrier
  • Accessory Hitch Reciever
  • Exterior Cooking Griddle w/ Metal Pullout Drawer
  • 6' Coiled Break Away Cable
  • Oversized Holding Tanks
  • Conventional Microwave
Ultimate Power Package
  • Electric Awning with LED Light
  • LED Interior Lighting
  • Motion Sensor Entry and Pass Thru Lighting (LED)
  • Bluetooth Stereo
  • High Definition LED Television
  • Detachable Marine Grade Power Cord
  • Ducted AC System
  • 30 AMP Service
  • Power Tongue Jack
  • Compass Connect
  • Tire Linc TPMS Prep
  • Exterior Cable Hookup
Four Season Protection Package
  • 25k BTU High Capacity Furnace
  • Heated and Enclosed Underbelly with Suspended Tanks
  • Designated Heat Duct to Subfloor
  • High Density Roof Insulation with Attic Vent
  • Moisture Barrier Floor Enclosure
  • Residential (Ductless) Heating System Throughout
  • Double Insulated Roof and Front Cap (R-40)
  • Heated and Enclosed Dump Valves
