Momentum MAV | 24MAV

Momentum MAV
22MAV

Hitch

915

UVW

5,600

Length

26' 6"

24MAV

Hitch

1,200

UVW

6,580

Length

29' 11"

NEW

27MAV

Hitch

1,200

UVW

6,835

Length

32' 2"

Build and Price your Grand Design RV GDRV

$0

Country Code US CA

Contact Method

Yes, I would like to receive text messages from Grand Design. **Standard message and data rates may apply. You may opt out at any time.*

*MSRP shown in USD. Pricing does not include freight, tax, title, license or dealer prep charges. Because of our commitment to continuous product improvement, Grand Design Recreational Vehicles reserves the right to change prices, components, standards, options, specifications, and materials without notice and at any time. Be sure to review current product details with your local dealer before purchasing.

Features and Packages
included in the starting price:

Hitch
1,200

UVW
6,580

GVWR
11,000

Length
29' 11"

Height
12' 2"

Sleeps
2

MSRP
$42,472

DOWNLOAD SPEC SHEET

Specifications
Features
Packages

OVERALL SIZE
Exterior Height	12' 2"
Exterior Height (w/opt. AC)
Exterior Length	29' 11"
Exterior Width	8' 4"
Exterior Width (w/ slide out)	N/A
Interior Height	7'

WEIGHTS
Hitch / Pin Weight	1,200 lbs.
UVW	6,580 lbs.
GVWR	11,000 lbs.

CAPACITY
Fresh Water Capacity	90 gal.
Gray Water Capacity	74 gal.
Waste Water Capacity	37 gal.
Propane Tanks	2
LPG	40
Sleeping Capacity	2
Fuel Capacity	N/A

APPLIANCES
Water Heater	Tankless
Refrigerator	8 cu. ft.
Furnace	30,000 BTU
AC	15,000 BTU

RUNNING GEAR
Axles	2
Wheel Size	15 in.
Tire Size	ST225/75R15LRE

CONSTRUCTION
Construction Type	Traditional
Floor R-Value	R-11
Wall R-Value	R-9
Roof R-Value	R-40
Slide Room R-Value	N/A
Garage R-Value	R-11

DIMENSIONS
Standard Bed	60 X 80 Queen Bed
Standard Bunk	N/A
Shower	27 x 36"
Garage Length	18'

EXTERIOR
Slides	N/A
Awnings	1
Awning Length	17'

EXTERIOR
Power Tongue Jack Solar Power Inlet 20# LP Bottles (2) with Cover Friction Hinge Entry Door Battery Kill Switch (Pass Thru) Oversized Tank Capacites Walk-on Roof Easy Access Low Point Drain Valves Main Floor Insulation (R-11) Undermount Spare Tire Magnetic Storage Door Catches Extended Grab Handle Power Awning Power Tongue Jack Dual 20#LP Tanks w/ Cover All in One Utility Center LP Quick Connect

CONSTRUCTION
TPO Roof Membrane w/ Limited Lifetime Warranty Insulated Storage Doors Side Walls Insulation (R-9) Slideroom Roof and End Wall Insulation (R-9) Roof Insulation (R-40) Tinted Windows TV Prep with Backer Heated & Enclosed Underbelly w/Suspended Tanks Dedicated Heat Duct to Subfloor Hi-Density Roof Insulation w/Thermofoil Moisture Barrier Floor Enclosure Elevated A-Frame Utility/Generator Rack No Wheel Wells in Garage

INTERIOR
Large Solid Bedroom Door (Master Suite) Residential Bedspread Cable/Sat Prep Walk-in Shower Power Vent Fan in Bath and Living Area Medicine Cabinet with Mirror ABS Tub Surround Solid Hardwood Drawer Fronts Solid Core Cabinet Stiles Pre-Drilled and Screwed Cabinetry Ball Bearing Full Extension Drawer Glides Residential Countertops Microwave 3-Burner Range with Oven USB Ports (2) Upgraded Residential Furniture More Power Outlets 84" Interior Height Solid Wood Drawer Fronts LED Interior Lights

KITCHEN
Deep Seated Stainless Steel Sink

ELECTRICAL
Motion Sensor Lights in Key Areas Detachable 50AMP Power Cord (N/A 22MAV) Battery Disconnect Switch HD TV Antenna

HVAC
15K Main AC Ducted 30K BTU Furnace Attic Vent EvenFlow Ductless Heating Throughout

PLUMBING
High-Capacity Water Pump Extra Large 2" Fresh Water Drain Valve 90 Gal. Fresh Water Capacity Black Tank Flush High Rise Faucet Tankless Water Heater Easy Winterization

BEDROOM
60 x 80 Queen Bed Gas Strut Lift Bed Storage

BATHROOM
Foot Flush Toilet

APPLIANCE
12V 8 Cu. Ft. Refer

GARAGE
24" DoveTail Loading Ramp Patio System Loading Lights E-Z Lift Bunk Bed Garage Pull Down Screen

Exterior Package
Power Awning Detachable 50AMP Power Cord (N/A 22MAV) Battery Disconnect Switch HD TV Antenna Power Tongue Jack Heated & Enclosed Underbelly w/Suspended Tanks Dedicated Heat Duct to Subfloor Hi-Density Roof Insulation w/Thermofoil Moisture Barrier Floor Enclosure Attic Vent Dual 20#LP Tanks w/ Cover EvenFlow Ductless Heating Throughout Easy Winterization All in One Utility Center LP Quick Connect

Solar Package
180W Solar Panel 40 Amp Charge Controller with Bluetooth Battery Monitor 12V Refrigerator

Luxury Interior Package

12V 8 Cu. Ft. Refer
Microwave
3 Burner Range
15K Main AC Ducted
84" Interior Height
60 x 80 Queen Bed
90 Gal. Fresh Water Capacity
Undermount Spare Tire
Black Tank Flush
Magnetic Storage Door Catches
Foot Flush Toilet
Extended Grab Handle
Gas Strut Lift Bed Storage
Tinted Windows
High Rise Faucet
Solid Wood Drawer Fronts
Tankless Water Heater
Deep Seated Stainless Steel Sink
TV Prep with Backer
LED Interior Lights
Motion Sensor Lights in Key Areas
30K BTU Furnace
Radial Tires
Two Euro Chairs (N/A 27MAV)

Garage / Cargo Package
24" DoveTail Loading Ramp 2,500lbs Tie Downs Anchored into Chassis Patio System Loading Lights No Wheel Wells in Garage E-Z Lift Bunk Bed Garage Pull Down Screen
