Reflection 100 Series | 27BH

Build and Price your Grand Design RV GDRV

$0

Country Code US CA

Contact Method

Yes, I would like to receive text messages from Grand Design. **Standard message and data rates may apply. You may opt out at any time.*

*MSRP shown in USD. Pricing does not include freight, tax, title, license or dealer prep charges. Because of our commitment to continuous product improvement, Grand Design Recreational Vehicles reserves the right to change prices, components, standards, options, specifications, and materials without notice and at any time. Be sure to review current product details with your local dealer before purchasing.

Features and Packages
included in the starting price:

Hitch
1,280

UVW
8,200

GVWR
10,195

Length
32' 3"

Height
12' 3"

Sleeps
10

MSRP
$52,657

DOWNLOAD SPEC SHEET

Specifications
Features
Packages

OVERALL SIZE
Exterior Height	12' 3"
Exterior Height (w/opt. AC)	12' 9"
Exterior Length	32' 3"
Exterior Width	8'
Exterior Width (w/ slide out)	11'
Interior Height	N/A

WEIGHTS
Hitch / Pin Weight	1,280
UVW	8,200
GVWR	10,195

CAPACITY
Fresh Water Capacity	55
Gray Water Capacity	78
Waste Water Capacity	39
Propane Tanks	2
LPG	60
Sleeping Capacity	10

APPLIANCES
Water Heater	Tankless
Refrigerator	10 cu. ft.
Furnace	30,000 BTU
AC	15,000 BTU

RUNNING GEAR
Axles	2
Wheel Size	15 in.
Tire Size	ST225/75R15 LRE

CONSTRUCTION
Construction Type	Aluminum Cage
Floor R-Value	R-30
Wall R-Value	R-9
Roof R-Value	R-40
Slide Room R-Value	R-9

DIMENSIONS
Standard Bed	60 X 80 Queen Bed
Standard Bunk	(2) 48x74" Bunks
Shower	30 x 48"

EXTERIOR
Slides	1
Awnings	1
Awning Length	20'

EXTERIOR
80% Tint Radius Safety Glass Windows Battery Kill Switch in Pass Thru Storage Area 30# LP Bottles (2) 30" Radius Entry Door Outside Shower Factory Installed Roof Ladder Exterior Cable Hookup (Sidewall)

CONSTRUCTION
Gel Coated Exterior Sidewalls Residential 5" Truss Rafters (16" O.C.) Walk On Roof Decking Double Insulated Roof & Front Cap One-Piece TPO Roof Membrane with Limited Lifetime Warranty Laminated Aluminum Framed Rear Wall (R-9) Laminated Aluminum Framed Side Walls (R-9) Laminated Aluminum Framed Roof and End Walls in Slide Rooms (R-9) Aluminum Framed Main Floor (R-30) Residential Wood Framed Roof (R-40)

RUNNING GEAR
Rubberized Suspension Equalizer Aluminum Wheels with E-Rated Tires Under Carriage Spare Tire and Carrier

INTERIOR
Matte Black Fixtures and Hardware Hardwood Galley Slide Trim Moldings Solid Hardwood Drawer Fronts Louvered Tread Steps to Bedroom Solid Core Cabinet Stiles Pre-Drilled and Screwed Cabinetry Ball Bearing Full Extension Drawer Glides Large Panoramic Slide Room Windows Heated Theater Seats w/LED Lights & Massage (Most Models) Premium Congoleum Flooring Ductless Flooring Throughout Living Area Residential Style Window Treatment LED Lighting with Motion Sensors (Key Areas)

KITCHEN
Deep Seated Stainless Steel Sink

ELECTRICAL
Marine Grade LED Hitch Light 180W Roof Mounted Solar Panel Roof Mounted Quick Connect Plugs 60 Amp Charge Controller Inverter Prep Solar Disconnect

HVAC
Adjustable A/C Vents 35K BTU High Capacity Furnace

PLUMBING
High-Capacity Water Pump with Interior and Exterior Switch Extra Large 2" Fresh Water Drain Valve Easy Access Low Point Drain Valves

BEDROOM
Functional Wardrobe Closet Oversized Bed Base Storage 60 x 80 Mattress with Residential Bedspread Bedroom Heat Registers

BATHROOM
30 x 36 Residential Walk-In Shower Heat Duct and A/C Vents in Bathroom Power Vent Fan Large Vanity Top w/ Deep Sink Large Medicine Cabinet with Mirror

APPLIANCE
12V 10 Cu. Ft. Refrigerator

ELECTRONICS
Cable/SAT Prep AM/FM HDMI Bluetooth Stereo

Peace of Mind Package

Residential Cabinetry
Universal All-In-One Docking Station
Metal Slam Latch Front Cargo Doors
On Demand Water Heater
Porcelain Toilet with Foot Flush
High-Rise Faucet with Pullout Sprayer
MORryde "Step Above" Entry Step
Theater Seats
Residential Booth Dinette
LP Quick Connect
Self-Adjusting Breaks
Pleated Shades
6' Coiled Break Away Cable
Deep Seated Stainless Steel Kitchen Sink
Walk-on Roof
Aluminum Rims
Spare Tire & Carrier
2” Receiver Hitch Upgrade

Ultimate Power Package
Microwave w/vented Range Hood 15K Ducted Main A/C "One-Touch" Electric LED Awning AM/FM HDMI Bluetooth Stereo 50 AMP Service Wired and Framed for 2nd A/C High Definition LED TV Detachable Power Cord with LED Light One-Touch Automatic Leveling System LED Interior Lighting Motion Sensor Entry Lighting (LED) Compass Connect Tire Linc TPMS Prep

Arctic 4-Seasons Protection Package
30K BTU High Capacity Furnace Double Insulated Roof & Front Cap Heated & Enclosed Dump Valves Heated & Enclosed Underbelly w/ Circulating Heat Thermofoil Insulation under Holding Tanks

Solar Package
180W Roof Mounted Solar Panel Roof Mounted Quick Connect Plugs 60 Amp Charge Controller 12V 10 Cu. Ft. Refrigerator Inverter Prep Solar Disconnect
